Choose your product
€749,00 * Incl. tax
We have 1 in stock Delivered within 3-5 working days
Pros and Cons
  • You can manage the charger through an app on your phone
  • Very high quality charger
  • Also available as socketed version
  • The charger has no display
  • This charger has no load balancing
  • The charger is not so small
Order even cheaper with combi solutions
Connection type: 1 phase, Maximum power: 16 amps
30mA Residual Current Circuit Breaker RCCB with Overcurrent Protection
€778,00 €768,00
One or two chargers: Two, Cable suspension system: No, Charger plate: 310x200-VRT
Design your own mounting pole
€1.048,00 €1.028,00
Cable holder and hanger for type 2 cables
€778,99 €769,00

Technical specifications

Phase 3
Ampere 32A
Power 22kW
Dimensions 400x250x105mm
30mA AC earth leakage protection Yes
6mA DC earth leakage protection Yes
Connectivity Yes
Fixed cable Yes
Cable length(s) 5m / 7,5m
kWh meter built-in Yes
RFID reader No
Display No
OCPP version supported -

Functional specifications

Load balancing support No
Vehicle to grid No
Postponed charging Yes
Controllable with APP Yes
Charging with the sun No
Manual settlement of charging sessions Yes
Automatic settling of charging sessions No

The smart choice

The Ratio Smart charging station is Ratio's latest extension EV chargers. This charging station comes with the Ratio app so you can access your charging station anytime, anywhere.

Designed and manufactured in the Netherlands, these Ratio chargers are well known for their very high quality, reliability and ease of use. This charging station meets all european quality and safety requirements and the clever design of the charging station ensures that you always have a place to hang your charging cable.
This charger comes in both 1 and 3 phase versions where the 3 phase version can also be used on 1 phase. This makes it possible to connect the charger to 1 phase first and upgrade your connection to 3 phase later if necessary.

With the Ratio App, you can

  • Gain insight into your current charging session
  • See an overview of your charging history
  • Lock or unlock the charger
  • Set charging schedules
  • Choosing the 'Plug & Charge' mode: this way you can simply start charging without cards or authorisation!
  • The charger is easy to configure via the installer menu in the Ratio app

Main features

  • Choice of 1- or 3-phase version
  • Choice of 5 or 7,5 meter cable
  • Control the charger with your phone
  • Plug & Charge mode: charging without charge card or app
  • Static Load Balancing
  • Earth fault protection: AC 30mA, DC 6mA
  • Beschermingsniveau IP54
  • 2 year warranty
  • 3 phase version also works on 1 phase

Documentation





  • Dimensions (lxbxh in mm):
  • Cable length (in meters):
  • Max Charging Speed in km/h:40 km/hour
  • Max Charging Speed in kW:7,4 kW
  • Plug type Car side:Type 2
  • Plug type Charge station side:Type 2
  • Cable Attached or Socket:Cable Attached
  • Display:No
  • Phases:1 or 3
  • Amperage:32
  • Network Technologies Supported:Wifi en Bluetooth
  • Mobile app Support:Yes
  • Remote station management:Yes
  • Scheduled Charging:Yes
  • Colour:Black
  • RFID reader:No
  • Load Balancing:Yes
  • Solar charging:
  • Plug & Charge Enabled:Yes
  • Requires Professional Installation:Yes
  • IP Rating:
  • Number of vehicles that can be charged:1
  • RCD type build in:30mA Type A
  • 6mA DC Current Detection:
  • Home Automation Support:No
  • MID certified meter:No
  • kWh meter Build in:No
  • Smart Tesla charge port opening :
