Choose your product
€959,00 * Incl. tax
We have 4 in stock Order before 23:45 - Delivered within 2-3 business days
Pros and Cons
  • RFID reader integrated
  • Suitable for automatic settlement
  • You can manage the charger through an app on your phone
  • Only available as socket version
  • Wired load balancing only
  • Only available in black
Order even cheaper with combi solutions
Connection type: 1 phase, Maximum power: 16 amps
30mA Residual Current Circuit Breaker RCCB with Overcurrent Protection
€988,00 €978,00
One or two chargers: Two, Cable suspension system: No, Charger plate: 310x200-VRT
Design your own mounting pole
€1.258,00 €1.238,00
Cable holder - black
Wall bracket
€998,99 €988,99
4 meter
Type 2 - Type 2 Charge Cable 32A 3 Phase, 4 to 12 meters
€1.138,00 €1.118,00

Technical specifications

_x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_
Phase3
Ampere32A
Power22kW
Dimensions260x192x113mm
30mA AC earth leakage protectionYes
6mA DC earth leakage protectionYes
ConnectivityYes
Fixed cableNo
Cable length(s)-
kWh meter built-inYes
RFID readerYes
DisplayNo
OCPP version supported1.6JSON
_x000D_



_x000D_

Functional specifications

_x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_ _x000D_
Load balancing supportYes
Vehicle to gridNo
Postponed chargingYes
Controllable with APPYes
Charging with the sunYes (i.c.w. Wallbox Powerboost)
Manual settlement of charging sessionsYes
Automatic settling of charging sessionsYes
_x000D_



_x000D_

Wallbox Copper SB

_x000D_

With the Wallbox Copper SB you are assured of a very complete system, with a maximum load capacity of 22kW and the possibility to automatically manage your charging session records (transactions) via our supporting back office services. With Wi-Fi, Bluetooth or ethernet connection you always have a connection to the Wallbox Copper SB and you can easily manage it with the Wallbox app. It also offers the options Load Balancing and Panel Sharing. These are suitable options for EVs with different charging capacities. The charging capacity is determined by the on-board charger of the battery in your car and by your electric grid connection.

_x000D_

With integrated socket

_x000D_

Copper SB comes with an integrated socket that gives you maximum flexibility. Charge type 1 and type 2 cars using your cable. The station is available with up to 22 kW charging speed.

_x000D_

Applicable to 1-phase and 3-phase connections

_x000D_

This smart Wallbox charging station is suitable for charging your car with a maximum of 3x32A (22 kW), but you can set this to values ​​between 6A and 32A so that this charging station can be perfectly applied to any grid connection and can deliver different charging capacities. With this you can charge any electric car!

_x000D_

The Wallbox Copper SB supports both 1-phase and 3-phase charging and is compatible with 1-phase and 3-phase grid connections. However, to be able to use more than 7.4 kW of power, you will need a 3-phase grid connection.

_x000D_

Supported charging speeds

_x000D_
    _x000D_
  • An electric car can drive an average of 5.5 km on 1 kWh of stored energy in the battery.
  • _x000D_
  • The maximum current for this charging station is 32A with a maximum of 3 phases (400V). If this charging point is connected to the maximum capacity of 3 phase 32A, it can deliver approximately 22 kW continuous power.
  • _x000D_
  • So if the car charges with the maximum 22kW, this means that it can charge 22 kWh (kilo Watt-hours) in one hour, which roughly corresponds to a range of 122 km (5.5 km x 22kWh).
  • _x000D_
  • This means, the maximum charging speed of this charging point is 122 km / hour when distributing 22kW.
  • _x000D_
_x000D_

Please note that the actual charging speed also depends on the charging speed of the car's onboard AC charger. Click here to find out which AC charger your car has.

_x000D_

Automated management of charging transactions

_x000D_

The use of OCPP (protocol) in the Wallbox Copper SB makes it possible to manage charging sessions/transactions with a connected back office system. This allows companies like leasing companies or employers with fleet cars to handle charging business comfortably. The Wallbox Copper is ideal for the business drivers who wants to keep track of their charging activity. The only thing that is needed besides the purchase and installation of the Wallbox Copper SB, is a subscription with a back office provider.

_x000D_

Soolutions can provide the connection to a supported back office system.

_x000D_

MyWallbox portal

_x000D_

Configure, monitor, and manage your Pulsar Plus from the myWallbox portal via a mobile app or web portal. The myWallbox portal gives you real-time information about consumption, charging time, and energy costs. You can set up the payload and lock (and unlock) the charging station to prevent abuse.

_x000D_

_x000D_

Wallbox app for smartphone and tablet

_x000D_

You can view and manage all device settings from your mobile phone or tablet via the Wallbox app. The app's functions include setting the charging current, locking and unlocking the charging station, scheduling charging sessions (for example, at the time when the energy price is lower) and moreFree DownloadFree download

_x000D_

Smart charging

_x000D_

Smart Charging is an additional option that you can choose for your charging station and is available for most charging stations that Cable Soolutions offers. With Smart Charging you can charge your EV smartly and efficiently, while the one-off and annual costs for your connection to the electricity grid are minimized. Smart Charging offers 2 options:

_x000D_
    _x000D_
  • Load Balancing: ensures that the charging vehicle never exceeds the peak power of your grid connection. This prevents additional costs from your utility company. The charger uses an additional communication link with an existing meter or with additional sensors to be fitted. This can differ per manufacturer.
  • _x000D_
  • Panel Sharing: allows you to connect multiple charging stations to one electrical connection and ensures that the available power of the entire electrical connection is smartly distributed, even if multiple vehicles are being charged When one of the vehicles is fully charged, the remaining charge capacity goes to the other vehicles that are still charging or connecting to the charger.
  • _x000D_
_x000D_

Smart Charging ensures that your charging station always makes smart use of the available charging capacity. By efficiently charging your electric car with a Smart Charging station, you can save up to hundreds of euros per year.

_x000D_

Dynamic Load Balancing

_x000D_

The Power Boost function ensures that you use the maximum residual current within your current electricity connection to charge your car as quickly as possible. And all this without you having to worry about whether your stop or the main fuse will fly out. Is your washing machine switched on? Then the car loads less quickly. In practice, the charging station is in constant contact with a smart module in the meter cupboard. This module continuously monitors how much power is available at that time. All electrical appliances in the house have priority over the charging station. The remaining capacity is available for charging the car. This ensures safe and optimal use of the power connection and overload is prevented.

_x000D_

Eco-Smart Solar EV Charging

_x000D_

Introducing Eco-Smart Solar EV Charging, intelligence that makes your Wallbox charger a key part of any sustainable home energy system. Use the green energy generated from your solar panels or wind turbines at home to charge your electric vehicle in the most efficient and sustainable way. With two modes to choose from, you decide when to go fully green or charge with a mix of green and grid energy. The Eco-Smart feature comes standard with Pulsar Plus and Copper SB models when equipped with the optional Power Boost function (load balancing).

_x000D_
    _x000D_
  • _x000D_

    Full-Green Mode

    _x000D_
  • _x000D_
_x000D_

Use exclusively green energy to charge your car. Full-Green mode will detect when there is enough surplus green energy available at your home to meet the minimum requirements needed to power your car. That’s when your car will begin charging, meaning every charge is 100% green.

_x000D_

_x000D_
    _x000D_
  • _x000D_

    Eco Mode

    _x000D_
  • _x000D_
_x000D_

Minimize the use of grid power while charging your EV by combining it with any surplus green energy available. Eco mode detects the green energy that is not being used elsewhere in your home in real-time and mixes it with energy from the grid to ensure a fast, efficient charge.

_x000D_

_x000D_

Please contact us

_x000D_

Cable Soolutions is happy to advise you on installation, energy management and other questions. Contact us if you would like to learn more about how you can take advantage of our smart EV chargers.

_x000D_



  • Dimensions (lxbxh in mm):260x192x113
  • Cable length (in meters):
  • Max Charging Speed in km/h:122 km/hour
  • Max Charging Speed in kW:tot 22kW
  • Plug type Car side:
  • Plug type Charge station side:Type 2
  • Cable Attached or Socket:Socket
  • Display:
  • Phases:Max 3 phase (also supports 1-2 phase installations)
  • Amperage:Max 32A
  • Network Technologies Supported:Wifi, Bluetooth and LAN
  • Mobile app Support:Yes, Wallbox app
  • Remote station management:Mywallbox https://wallbox.com/en_catalog/mywallbox
  • Scheduled Charging:Yes, via app and cloud services
  • Colour:Black
  • RFID reader:Yes
  • Load Balancing:Yes, load balancing via optional Power Booster
  • Solar charging:
  • Plug & Charge Enabled:yes
  • Requires Professional Installation:Yes
  • IP Rating:IP54
  • Number of vehicles that can be charged:1
  • RCD type build in:30mA Type A
  • 6mA DC Current Detection:Yes
  • Home Automation Support:No
  • MID certified meter:Yes
  • kWh meter Build in:Yes
  • Smart Tesla charge port opening :No
